LENOVO Heavenly iSpinit1248G switche user manual

This is the user manual of Lenovo iSpirit 1248G switch, which introduces the basic functions and usage methods of the switch.

Brand: Lenovo
Category: Network Switches
Document type: User Manual
Language: Chinese
Pages: 8
File format: PDF
File size: 301 KB
Updated: 30 September, 2023
MD5 checksum: E8578054E8EDD68C38D4EC44DC4C9C14
PDF: LENOVO Heavenly iSpinit1248G switche user manual PDF

About this manual

The iSpirit1248G is a managed Ethernet switch that supports 10/100/1000 Mbps operation with auto‑MDI/MDIX uplink ports. The document describes the product’s features, hardware layout, and software capabilities, including LED indicators and flow‑control support.

Installation procedures, wiring diagrams, hardware specifications, and a troubleshooting guide are included, along with contact information for Lenovo support. This manual is written in Chinese.

What's inside

Product Overview
Installation Guide
Hardware Specifications
Software Functions
LED Indicators
Technical Data
Troubleshooting
Support Information

Specifications

Supported Ethernet speeds	10/100/1000 Mbps
Uplink port type	MDI/MDIX
IEEE 802.3x flow control	Supported
Operating voltage	180‑264 VAC, 47/63 Hz
Dimensions (W×H×D)	440 mm × 260 mm × 44 mm
LED indicators	PowerLink / ActLink / Activity LEDs

Frequently asked questions

Does the iSpirit1248G support IEEE 802.3x flow control?

Yes, the switch supports IEEE 802.3x flow control.

What Ethernet speeds can the iSpirit1248G operate at?

It can operate at 10 Mbps, 100 Mbps, and 1000 Mbps.

What is the operating voltage range of the iSpirit1248G?

The switch works with an input voltage of 180 V to 264 V AC at 47/63 Hz.

What LED indicators are provided on the iSpirit1248G?

The device includes PowerLink, ActLink and Activity LEDs.
