This manual begins with important safety instructions, covering electrical shock hazards, proper ventilation, grounding, and handling of the unit. It also details installation steps such as mounting, antenna grounding, and power‑source requirements.
The remainder of the guide explains how to connect speakers, audio/video sources, and remote‑control setup, and describes the receiver’s features—including built‑in 6‑channel amplification, Dolby/DTS decoding, XM Satellite Radio, and various sound‑field programs—along with troubleshooting and specifications.
| Front channel output power | 90 W per channel |
|---|---|
| Center channel output power | 90 W |
| Surround channel output power | 90 W per channel |
| Surround back channel output power | 90 W |
| Minimum RMS output power | 0.06 % THD, 20 Hz‑20 kHz, 8 Ω |
| Voltage selector (Asia model) | 220‑240 V AC, 50/60 Hz |
| Voltage selector (General model) | 110‑240 V AC, 50/60 Hz |
| Digital‑to‑Analog converter | 192 kHz / 24‑bit |
Open the battery compartment, insert the two supplied AA (R6, UM‑3) batteries with the correct polarity, and snap the cover back into place.
Read all safety and operating instructions, keep ventilation space around the unit, avoid water and moisture, do not open the cabinet, unplug before cleaning, and use only approved accessories.
Locate the voltage selector on the rear panel and set it to the appropriate voltage (e.g., 220‑240 V for Asia models or 110‑240 V for General models) before plugging the unit into the wall outlet.
