This document is an installation and user manual for DTSH V3 electronic lock. The product is suitable for hotel electronic locks and features the use of mechanical lock bodies that comply with the German standard DIN18251. It can be installed on city doors or emergency doors. The document provides detailed installation and usage instructions, as well as methods for programming cards, sales cards, and door opening cards. It also introduces other accessories and technical specifications.
The DTSH V3 is a hotel‑grade electronic lock from HAFele, designed for interior and fire‑rated doors and equipped with wireless communication, emergency mechanical key, and battery power. It complies with German DIN18251 standards and offers optional fire‑rated configurations.
The manual covers the complete installation process, programming of access cards, battery replacement, emergency mechanical key use, common troubleshooting questions, and technical specifications such as dimensions, power supply, temperature and humidity limits. This manual is written in Chinese.
| Size (H × W × L) | 26 × 65 × 227 mm |
|---|---|
| Power Supply | 4 × 1.5 V AA batteries |
| Relative Humidity | 0 % – 90 % (non‑condensing) |
First delete all existing access cards using the “delete all cards” procedure, then program new cards with the programming card.
