RemoDAQ-8024B is a 4-channel analog output module that supports modbus/rtu protocol. It has 12-bit resolution, +/-10V range, +/-0.1% FSR current output accuracy, +/-0.2% FSR voltage output accuracy, +/-30μV/℃ zero drift, 0.2μ A/℃ temperature drift, 4 isolated logic input channels, +1V max level 0 and +10-30Vdc level 1, +/-35V overvoltage protection and other features.
The RemoDAQ-8000 series is a data‑collection and control module that uses RS‑485 and supports Modbus‑RTU. The RemoDAQ-8024B model offers four analog input channels, digital I/O, timers, counters, and AC measurement functions, all controllable via remote commands.
The manual describes terminal distribution, wiring connections, device specifications such as 12‑bit resolution and ±10 V/±20 mA input ranges, as well as special operating modes like TNTT and Dual‑Watch to restore default settings and improve reliability. This manual is written in Chinese.
| Resolution | 12 Bits |
|---|---|
| Current Input Range | ±20 mA |
| Accuracy | -0.1% FSR |
| Power Consumption | I_W @ 24 VDC |
The default baud rate is 9600 bps.
