Panasonic PT-DZ21K2 PT-DS20K2 PT-DW17K2 PT-DZ16K2 Error Codes: List of 103 Codes and Their Meaning

This is the list of error, warning codes the Panasonic manual gives for the PT-DZ21K2 PT-DS20K2 PT-DW17K2 PT-DZ16K2 Panasonic projector. Find your code below and open it for what the manual says about its causes and what to do.

Error codes from p. 190

Code	What it means	Page
`U04`	Air filter clogging	p. 190
`U11`	Intake temperature warning	p. 190
`U12`	Optical module temperature warning	p. 190
`U13`	Exhaust air temperature warning	p. 190
`U14`	Low temperature warning	p. 190
`U21`	Intake temperature error	p. 190
`U22`	Optical module temperature error	p. 190
`U23`	Exhaust air temperature error	p. 190
`U24`	Low temperature error	p. 190
`U30`	Installation angle error	p. 190
`U31`	Portrait installation angle error	p. 190
`U32`	Used lamp unit error	p. 190
`U33`	Used lamp unit mix-up error	p. 190
`U35`	Non-compatible lamp warning	p. 190
`U41`	Lamp 1 runtime warning	p. 190
`U42`	Lamp 2 runtime warning	p. 190
`U43`	Lamp 3 runtime warning	p. 190
`U44`	Lamp 4 runtime warning	p. 190
`U51`	Lamp 1 error	p. 190
`U52`	Lamp 2 error	p. 190
`U53`	Lamp 3 error	p. 190
`U54`	Lamp 4 error	p. 190
`U61`	Lamp 1 runtime has exceeded 3 000 hours³	p. 190
`U62`	Lamp 2 runtime has exceeded 3 000 hours³	p. 190
`U63`	Lamp 3 runtime has exceeded 3 000 hours³	p. 190
`U64`	Lamp 4 runtime has exceeded 3 000 hours³	p. 190
`U71`	Lamp 1 not installed	p. 190
`U72`	Lamp 2 not installed	p. 190
`U73`	Lamp 3 not installed	p. 190
`U74`	Lamp 4 not installed	p. 190
`U76`	Air filter unit not installed	p. 190
`U78`	Clog sensor error	p. 190
`U81`	Low AC voltage warning (below 170 V)	p. 190
`F91`	FPGA1/2 configuration error	p. 192
`F92`	FPGA3 configuration error	p. 192
`F96`	Lens mounter error	p. 192
`FE0`	Color prism fan 4 error	p. 192
`FE1`	Exhaust fan 1 error	p. 192
`FE2`	Exhaust fan 2 error	p. 192
`FE3`	Exhaust fan 3 error	p. 192
`FE4`	Exhaust fan 4 error	p. 192
`FE5`	Intake fan 1 error	p. 192
`FE6`	Intake fan 2 error	p. 192
`FE7`	Lamp 1 fan error	p. 192
`FE8`	Lamp 2 fan error	p. 192
`FE9`	Lamp 3 fan error	p. 192
`FF0`	Lamp 4 fan error	p. 192
`FF1`	Lamp 1/2 power supply fan error	p. 192
`FF2`	Lamp 3/4 power supply fan error	p. 192
`FF3`	Power supply fan error	p. 192
`FF4`	Signal fan error	p. 192
`FF5`	Lamp 1/2 relay fan error	p. 192
`FF6`	Lamp 3/4 relay fan error	p. 192
`FF7`	Color prism fan 1 error	p. 192
`FF8`	Color prism fan 2 error	p. 192
`FF9`	Color prism fan 3 error	p. 192
`FJ0`	Liquid cooling pump R error	p. 192
`FJ1`	Liquid cooling pump G error	p. 192
`FJ2`	Liquid cooling pump B error	p. 192

Warning codes from p. 191

Code	What it means	Page
`UA1`	FPGA temperature warning	p. 191
`UA4`	Power supply temperature error	p. 191
`UA5`	FPGA temperature error	p. 191
`H01`	Battery replacement for the internal clock	p. 191
`H11`	Intake temperature sensor not present	p. 191
`H12`	Optical module temperature sensor not present	p. 191
`H13`	Exhaust air temperature sensor not present	p. 191
`H18`	Clog sensor not present	p. 191
`F00`	Liquid cooling pump R warning	p. 191
`F01`	Liquid cooling pump G warning	p. 191
`F02`	Liquid cooling pump B warning	p. 191
`F11`	Shutter error	p. 191
`F12`	Dynamic in's error	p. 191
`F13`	Air filter unit error	p. 191
`F15`	Luminance sensor error	p. 191
`F16`	Angle sensor error	p. 191
`F41`	Lamp 1 memory error	p. 191
`F42`	Lamp 2 memory error	p. 191
`F43`	Lamp 3 memory error	p. 191
`F44`	Lamp 4 memory error	p. 191
`F50`	Exhaust fan 1 warning	p. 191
`F51`	Exhaust fan 2 warning	p. 191
`F52`	Exhaust fan 3 warning	p. 191
`F53`	Exhaust fan 4 warning	p. 191
`F54`	Intake fan 1 warning	p. 191
`F55`	Intake fan 2 warning	p. 191
`F56`	Lamp 1 fan warning	p. 191
`F57`	Lamp 2 fan warning	p. 191
`F58`	Lamp 3 fan warning	p. 191
`F59`	Lamp 4 fan warning	p. 191
`F61`	Lamp 1 power supply communication error	p. 191
`F62`	Lamp 2 power supply communication error	p. 191
`F63`	Lamp 3 power supply communication error	p. 191
`F64`	Lamp 4 power supply communication error	p. 191
`F70`	Lamp 1 power supply fan warning	p. 191
`F71`	Lamp 2 power supply fan warning	p. 191
`F72`	Power supply fan warning	p. 191
`F73`	Signal fan warning	p. 191
`F74`	Lamp 1/2 relay fan warning	p. 191
`F75`	Lamp 3/4 relay fan warning	p. 191
`F76`	Color prism fan 1 warning	p. 191
`F77`	Color prism fan 2 warning	p. 191
`F78`	Color prism fan 3 warning	p. 191
`F79`	Color prism fan 4 waming	p. 191
