ASUS MAXIMUS V FORMULA Series Error Codes

80 codes from pages 50–54 of the manual

This is the list of error codes the ASUS manual gives for the MAXIMUS V FORMULA Series motherboard. Find your code below and open it for what the manual says about its causes and what to do.

Error codes from p. 50

CodeWhat it meansPage
30 Reserved for ASL (see ASL Status Codes section below) p. 50
31 Memory Installed p. 50
4F DXE IPL is started p. 50
54 Unspecified memory initialization error p. 50
55 Memory not installed p. 50
56 Invalid CPU type or Speed p. 50
57 CPU mismatch p. 50
58 CPU self test failed or possible CPU cache error p. 50
59 CPU micro-code is not found or micro-code update is failed p. 50
00 Not used p. 50
01 Power on. Reset type detection (soft/hard). p. 50
02 AP initialization before microcode loading p. 50
03 System Agent initialization before microcode loading p. 50
04 PCH initialization before microcode loading p. 50
06 Microcode loading p. 50
07 AP initialization after microcode loading p. 50
08 System Agent initialization after microcode loading p. 50
09 PCH initialization after microcode loading p. 50
0B Cache initialization p. 50
0E Microcode not found p. 50
0F Microcode not loaded p. 51
10 PEI Core is started p. 51
5A Internal CPU error p. 51
5B Reset PPI is not available p. 51
E0 S3 Resume is stared (S3 Resume PPI is called by the DXE IPL) p. 51
E1 S3 Boot Script execution p. 51
E2 Video repost p. 51
E3 OS S3 wake vector call p. 51
E4 Reserved for future AMI progress codes p. 51
E5 Reserved for future AMI progress codes p. 51
E6 Reserved for future AMI progress codes p. 51
E7 Reserved for future AMI progress codes p. 51
E8 S3 Resume Failed p. 51
E9 S3 Resume PPI not Found p. 51
EA S3 Resume Boot Script Error p. 52
EB S3 OS Wake Error p. 52
F0 Recovery condition triggered by firmware (Auto recovery) p. 52
F1 Recovery condition triggered by user (Forced recovery) p. 52
F2 Recovery process started p. 52
F4 Recovery firmware image is loaded p. 52
F5 Reserved for future AMI progress codes p. 52
F6 Reserved for future AMI progress codes p. 52
F7 Reserved for future AMI progress codes p. 52
F8 Recovery PPI is not available p. 52
F9 Recovery capsule is not found p. 52
FA Invalid recovery capsule p. 52
60 DXE Core is started p. 52
61 NVRAM initialization p. 52
62 Installation of the PCH Runtime Services p. 52
68 PCI host bridge initialization p. 52
69 System Agent DXE initialization is started p. 52
6A System Agent DXE SMM initialization is started p. 52
70 PCH DXE initialization is started p. 52
71 PCH DXE SMM initialization is started p. 52
72 PCH devices initialization p. 52
78 ACPI module initialization p. 52
79 CSM initialization p. 52
80 Boot Device Selection (BDS) phase is started p. 52
91 Driver connecting is started p. 52
B1 Runtime Set Virtual Address MAP End p. 54
B2 Legacy Option ROM Initialization p. 54
B3 System Reset p. 54
B4 USB hot plug p. 54
B5 PCI bus hot plug p. 54
B6 Clean-up of NVRAM p. 54
B7 Configuration Reset (reset of NVRAM settings) p. 54
B8 Reserved for future AMI codes p. 54
D0 CPU initialization error p. 54
D1 System Agent initialization error p. 54
D2 PCH initialization error p. 54
D3 Some of the Architectural Protocols are not available p. 54
D4 PCI resource allocation error. Out of Resources p. 54
D5 No Space for Legacy Option ROM p. 54
D6 No Console Output Devices are found p. 54
D7 No Console Input Devices are found p. 54
D8 Invalid password p. 54
D9 Error loading Boot Option (Loadimage returned error) p. 54
DA Boot Option is failed (StartImage returned error) p. 54
DB Flash update is failed p. 54
DC Reset protocol is not available p. 54
