Key facts
- Manuals
- 23
- Categories
- 1
- Languages
- ZH · JA · EN
- Last added
- 2012-03-15
Featured MODEL manuals
MET ONE INSTRUMENTS Model 804 Air Particle Counter User Manual
This manual provides step‑by‑step instructions for operating the Model 804 air particle counter, including how to select measurement channels, set sample time, and navigate the LCD interface. Safety warnings and calibration procedures are also covered.
Technical details such as particle size range, accuracy, flow rate, memory capacity and power specifications are listed, along with warranty information and service contacts. This manual is written in Chinese.
Covers: Operation Overview · Measurement Channels · Sample Settings · Alarms and Warnings · History and Data Logging · Calibration
GZ Kehua XR63/64/65 Pressure Regulators Product Leaflet
The XR63, XR64 and XR65 pressure regulators are designed for semiconductor process applications, offering smooth operation, ultra‑clean handling, and digital pressure display. They provide low‑pressure (≈0.5 MPa) and flow ranges from a few mL/min up to 5 L/min, with stable pressure drop and high reliability.
The document lists manufacturing specifications, material options, flow‑characteristic data, connection dimensions, and optional accessories. It also includes safety cautions and ordering instructions for custom configurations. This manual is written in Japanese.
Covers: Overview · Features · Manufacturing Specifications · Flow Characteristic Data · Connection Details · Material Options
GZKEHUA ZT60 Digital Pressure Gauge Product Leaflet
The ZT60 is a semiconductor‑based digital pressure gauge designed for industrial process gases. It features a durable Co‑Ni alloy sensor, SUS316L fittings, and a bright 4‑digit LED display that can be oriented vertically or horizontally. Intelligent functions such as loop‑check, scaling, zero‑adjust, and various output modes provide high‑accuracy measurement.
The gauge supports comparator NPN open‑collector outputs, 4‑20 mA or 1‑5 V DC analog output, and operates from 12‑24 V DC. It is available with horizontal or vertical mounting options and a range of connector types, making it adaptable to many installation scenarios. This manual is written in Japanese.
Covers: Overview · Features · Specifications · Outputs · Accuracy · Scaling Function
GZKEHUA ZT60 Digital Pressure Gauge User Manual
The ZT60 is a semiconductor‑based digital pressure gauge designed for industrial process gases. It features a large 4‑digit LED display, selectable orientation, and intelligent functions such as loop‑check, scaling, and zero‑adjust.
The manual covers the gauge's specifications, output options (comparator and analog), power requirements, connector types, installation configurations, and safety precautions, allowing users to set up and operate the instrument correctly. This manual is written in Japanese.
Covers: Overview · Features · Specifications · Output Options · Accuracy · Scaling Function
Latest MODEL manuals
MET ONE INSTRUMENTS Model 804 Air Particle Counter User Manual
User Manual 14 pages · 1009 KB · ZHThe MET ONE INSTRUMENTS Model 804 manual explains operation, setup, alarms and specifications of the air particle counter.
GZ Kehua XR63/64/65 Pressure Regulators Product Leaflet
Product Leaflet 6 pages · 210 KB · JATechnical overview and specifications for GZ Kehua XR63, XR64 and XR65 pressure regulators.
GZKEHUA ZT60 Digital Pressure Gauge Product Leaflet
Product Leaflet 5 pages · 290 KB · JAThe ZT60 digital pressure gauge from GZKEHUA offers a semiconductor sensor, large LED display, multiple output options, and selectable mounting configurations.
GZKEHUA ZT60 Digital Pressure Gauge User Manual
User Manual 5 pages · 290 KB · JAThe ZT60 digital pressure gauge manual provides specifications, installation options, and operation instructions for the device.
Pepperl + Fuchs KJ96 Pressure Transmitter Datasheet
Datasheet 8 pages · 529 KB · JATechnical data sheet for the KJ96 intrinsically safe explosion‑proof pressure transmitter.
KJ95 Intrinsic Safety Construction Pressure Transmitter Manual
User Manual 5 pages · 159 KB · JAManual for the KJ95 intrinsic‑safety pressure transmitter, covering safety features, specifications, and connection options.
ZT77 Digital Pressure Gauge User Manual
User Manual 5 pages · 184 KB · JAManual for the ZT77 digital pressure gauge, covering specifications, connections, and operation.
Model KJ95 Pressure Transmitter Intrinsic Safety Manual
User Manual 5 pages · 159 KB · JAThe Model KJ95 intrinsic safety pressure transmitter manual provides specifications, safety ratings, connection details, and operating ranges.
XR65 Pressure Regulator User Manual
User Manual 2 pages · 260 KB · JAThe XR65 pressure regulator manual provides specifications, installation options, and operating details for semiconductor process applications.
GZKEHUA ZT30 Electronic Pressure Switch User Manual
User Manual 5 pages · 236 KB · JAThe ZT30 electronic pressure switch manual explains features, specifications, wiring and operation for industrial use.
GZ Kehua XR63/64/65 Pressure Regulators Product Leaflet
Product Leaflet 6 pages · 210 KB · JAThe GZ Kehua XR63, XR64, and XR65 pressure regulators are described with specifications, flow rates, and connection details.
Bauerau XR67 Pressure Regulator User Manual
User Manual 3 pages · 551 KB · JAThe XR67 pressure regulator manual provides specifications, material details, and ordering options for medium‑flow semiconductor process applications.
GZ Kehua ZT77 Digital Pressure Gauge Manual
User Manual 5 pages · 206 KB · JAThe GZ Kehua ZT77 digital pressure gauge manual provides specifications, connection options, and operating details for this compact semiconductor‑gauge device.
Futek Model 251 RS-232/RS-485 Interface Converter User Manual
User Manual 1 pages · 34 KB · ZHThe Futek Model 251 converts RS‑232 signals to RS‑485 using RTS control and requires a +9 VDC@200 mA power source.
Kyoritsu Model 2000/2001 Digital Multimeter User Manual
User Manual 8 pages · 347 KB · ENUser manual for the Kyoritsu Model 2000/2001 digital multimeter covering specifications, safety, and operation.
- 1
- 2
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in MODEL manuals
What particle size range can the Model 804 measure?
It measures particles from 0.3 µm up to 10 µm.
From: MET ONE INSTRUMENTS Model 804 Air Particle Counter User Manual
How long does the device run on a full battery charge?
A fully charged unit operates for about 2.5 hours.
From: MET ONE INSTRUMENTS Model 804 Air Particle Counter User Manual
What is the maximum flow rate for the XR64 pressure regulator?
The XR64 can deliver either 50 L/min or 100 L/min under normal conditions.
From: GZ Kehua XR63/64/65 Pressure Regulators Product Leaflet
What primary pressure does the XR65 support?
The XR65 is rated for a primary pressure of 5 MPa.
From: GZ Kehua XR63/64/65 Pressure Regulators Product Leaflet
How can the display orientation be changed?
The 4‑digit LED display can be set to either vertical or horizontal orientation according to user preference.
What mounting configurations are supported?
The gauge can be installed horizontally or vertically, and it offers a variety of connector types and thread options.
