Hamamatsu Manuals

ManualLib has 26 Hamamatsu manuals covering 1 model. The most documented models are L2D2. Every file can be read online or downloaded as a PDF for free.

User Manual 1Datasheet 1

Key facts

Manuals
26
Models
1
Languages
EN
Last added
2012-08-10

Hamamatsu models by category

Other 1
L2D2

Latest Hamamatsu manuals

  • HAMAMATSU L2D2 LAMPS Manual

    The document describes the best electrode technology supported by the best light source, and provides detailed information on the features and performance of L2D2 lamps.

  • HAMAMATSU L7901-01 handbook

    The 100 kV MICROFOCUS X-RAY SOURCE L7901-01 is a sealed-off type X-ray source with a built-in power supply, 5µm focal spot size and 100kV and 100µA maximum output. It is easy to handle and operate, with no high voltage wiring and a built-in external control function.

  • HAMAMATSU L6690 handbook

  • HAMAMATSU L6622-01 Manual

    The document introduces a new 130 kV microfocus X-ray source, L6622-01, and its features and applications. The features include a 10 µm focal spot size, easy handling, continuous operation, and built-in external control function. The applications include X-ray non-destructive testing of printed circuits, electronic components, semiconductor devices, ceramics, soldered parts, rubbers, combinated materials, plastics, new materials, and die casting. Additionally, the product is suitable for multilayer printed circuit board X-ray inspection, industrial on-line process control and measurement, and industrial X-ray computer tomography system.

  • HAMAMATSU L7684/L7685/L6604/L6605 Manual

    The document describes a xenon flash lamp with high stability and high input energy, featuring long life and short arc length. It is suitable for applications such as high-speed imaging and pollution analysis.

  • HAMAMATSU PHOTOMULTIPLIER TUBES R7311 R7511 Data Sheet

    This document describes the features and characteristics of the R7311 and R7511 photomultiplier tubes, including sensitivity in the vacuum ultraviolet region, high quantum efficiency, and high anode sensitivity.

  • HAMAMATSU S7727 Photo IC for optical link

    S7726 and S7727 are designed for high-speed POF (Plastic Optical Fiber) communications. Both devices are molded into miniature plastic packages with lenses, allowing easy and efficient coupling to a POF. S7727 uses a monolithic photo IC that ensures high resistance to external noise and high reliability, and provides P-ECL voltage conversion output.

  • HAMAMATSU 1/2-inch CCD Video Camera C5405-50/-51 DATA SHEET

    The document introduces a new compact B/W camera C5405-50/-51, which incorporates a next generation 1/2-inch CCD. It features high resolution, sensitivity, and S/N ratio. The camera has an electronic shutter function for monitoring moving objects. It also has high sensitivity, high S/N ratio, small readout noise, and high resolution.

  • HAMAMATSU G8422/G8372/G5852 series InGaAs PIN photodiode

    InGaAs PIN long wavelength (up to 2.1 µm) photodiode G8422/G8372/G5852 series features include cut-off wavelength of 2.1 µm, 3-pin TO-18 package low price, TE-cooled type TO-8 package low dark current, active area of f0.3 to f3 mm. Applications include gas analyzer, water content analyzer and near infrared photometry.

  • HAMAMATSU SUPER-QUIET MERCURY-XENON LAMPS

    The document describes a high stability Mercury-Xenon Lamp that provides high intensity and radiant energy in the ultraviolet region. It is suitable for applications such as semiconductor inspection, blood analysis, and UV curing.

  • HAMAMATSU PHOTOMULTlPLlER TUBES R1527 R1527P(For Photon Counting)

    Hamamatsu R1527 features high cathode sensitivity, high current amplification, and low dark current. It is useful for fluorescence, chemiluminescence, Raman spectroscopy, and low light level detection.

  • HAMAMATSU P2825 SERIES Data Sheet

    This document is the copyright statement of ICminer.com Electronic-Library Service, providing information on querying suppliers of P2825.

  • HAMAMATSU C2955 handbook

    The product is an optical endoscope that uses an infrared light source to penetrate the silicon substrate to observe the IC's interconnect lines, wiring status, die bonding conditions, and diffusion zone conditions without damaging the observed part.

  • HAMAMATSU L2791 series Data Sheet

    This datasheet mainly introduces the features and characteristics of L2791 series infrared LEDs, including small emission spot, uniform emission, narrow directivity, etc. These products are suitable for applications such as automatic control systems, optical switches, and auto-focus.

  • HAMAMATSU NEW COMPACT TYPE PMT SERIES

    This document introduces the features and characteristics of HAMAMATSU's new compact side-on PMT series. The series has a wider X-axis anode uniformity, which improves detection efficiency and makes optical alignment easier. The R6357 is a unique addition, it is a new meshless multialkali compact PMT with over 100mA/W photocathode radiant sensitivity.

Which document do I need?

User Manual

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Datasheet

Ratings, dimensions and ordering codes, for selection and design work.

Questions answered in Hamamatsu manuals

What is the frame rate of the C7921 sensor?

The C7921 delivers 16 frames per second when using 4 × 4 binning.

From: Hamamatsu C7921 Flat Panel Sensor User Manual

What power supplies are required for the sensor?

It needs +5.0 V for A.Vdd and D.Vdd (±0.1 V) and +7.5 V (±0.5 V) for the analog supply.

From: Hamamatsu C7921 Flat Panel Sensor User Manual

What is the recommended supply voltage range for the C5923 board?

The recommended supply voltage is between +14.5 V and +15.5 V.

From: Hamamatsu C5923 Signal Processing Circuit for 1-D PSD Datasheet

What is the output offset voltage range?

The output offset voltage can be adjusted from -10 mV to +10 mV.

From: Hamamatsu C5923 Signal Processing Circuit for 1-D PSD Datasheet
