Quantum Manuals

ManualLib has 28 Quantum manuals. Every file can be read online or downloaded as a PDF for free.

Product Leaflet 2User Manual 1

Key facts

Manuals
28
Languages
ZH
Last added
2012-07-12

Latest Quantum manuals

  • Quantum RPM Cartridge Filters Owners Manual

  • QUANTUM Nitrox Dive Computer User's Guide

    This manual provides detailed instructions on how to use the QUANTUM Nitrox Dive Computer, including both on and under the water, and provides detailed warnings and alarms.

  • Quantum Leap Stormdrum 2 Virtual Instrument user manual

    The Quantum Leap Stormdrum 2 Virtual Instrument Users’ Manual is a user manual for the Quantum Leap Stormdrum 2 virtual instrument. The manual describes the features and characteristics of the software.

  • QUANTUM RESEARCH GROUP QT1101-ISG 10 KEY QTOUCH SENSOR IC Manual

    QT1101-ISG 10 KEY QTOUCH™ SENSOR IC is a self-contained, patented digital controller capable of detecting near-proximity or touch on up to 10 electrodes. It allows electrodes to project independent sense fields through any dielectric such as glass or plastic. This capability coupled with its continuous self-calibration feature can lead to entirely new product concepts, adding high value to product designs. The devices are designed specifically for human interfaces, like control panels, appliances, gaming devices, lighting controls, or anywhere a mechanical switch or button may be found; they may also be used for some material sensing and control applications. Each of the channels operates independently of the others, and each can be tuned for a unique sensitivity level by simply changing a corresponding external Cs capacitor. Patented AKS™ Adjacent Key Suppression suppresses touch from weaker responding keys and allows only a dominant key to detect, for example to solve the problem of large fingers on tightly spaced keys. Spread spectrum burst technology provides superior noise rejection. These devices also have a SYNC/LP pin which allows for synchronization with additional similar parts and/or to an external source to suppress interference, or, an LP (low power) mode which conserves power.

  • QUANTUM RESEARCH GROUP QT1100A-ISG Manual

    The QT1100A-ISG is an advanced 10-key QTOUCH™ sensor IC suitable for applications such as appliance controls, pointing devices, gaming machines, PC peripherals, television controls, and instrument panels. This device allows each electrode to project an independent sense field through glass or plastic. It is designed specifically for human interfaces, such as control panels, appliances, gaming devices, lighting controls, or anywhere a mechanical switch may be found. Each key channel operates independently and can be tuned to a unique sensitivity level by changing setup values in an EEPROM or via a serial interface. It includes patent pending AKS™ Adjacent Key Suppression, which suppresses touch from weakly responding keys and allows only a dominant key to detect, solving the problem of large fingers on tightly spaced keys. Modulated burst technology provides superior noise rejection. 'Fast-DI' operation works to further suppress false activations due to noise. These devices also have a Sync pin to suppress some forms of external interference.

  • QUANTUM QT1080 handbook

    QT1080 8 KEY QTOUCH™ SENSOR IC is an IC chip for touch screen with 8 touch points

  • QUANTUM RESEARCH GROUP - lQ QProx QT140 QT150 4 AND 5 KEY QTOUCH SENSOR ICs APPLICATIONS Instrument panels Gaming machine

    The QT140 / QT150 charge-transfer (“QT”) QTouch ICs are self-contained digital controllers capable of detecting near-proximity or touch on 4 or 5 electrodes. They allow electrodes to project independent sense fields through any dielectric like glass, plastic, stone, ceramic, and wood. They can also turn metal-bearing objects into intrinsic sensors, making them responsive to proximity or touch. Each of the channels operates independently of the others, and each can be tuned for a unique sensitivity level by simply changing its sample capacitor value. The devices are designed specifically for human interfaces, like control panels, appliances, gaming devices, lighting controls, or anywhere a mechanical switch or button may be found; they may also be used for some material sensing and control applications.

  • QUANTUM QT240 Data Sheet

    The QT240 charge-transfer (“QT’”) QTouch IC is a self-contained digital sensor IC capable of detecting near-proximity or touch on 4 electrodes. It allows electrodes to project independent sense fields through any dielectric like glass, plastic, stone, ceramic, and wood. It can also turn metal-bearing objects into intrinsic sensors, making them responsive to proximity or touch. This capability coupled with its continuous self-calibration feature can lead to entirely new product concepts, adding high value to product designs.

  • QUANTUM RESEARCH GROUP QT220 2 KEY QTOUCH SENSOR IC handbook

    The QT220 is a self-contained digital sensor IC capable of detecting near-proximity or touch on 2 electrodes. It allows electrodes to project independent sense fields through any dielectric like glass, plastic, stone, ceramic, and wood. It can also turn metal-bearing objects into intrinsic sensors, making them responsive to proximity or touch. This capability coupled with its continuous self-calibration feature can lead to entirely new product concepts, adding high value to product designs. Each of the channels operates independently of the other, and each can be tuned for a unique sensitivity level by simply changing its sample capacitor value. Two speeds are supported, one of which consumes only 90µA of typical current at 4V. Unique among capacitance sensors, the device incorporates spread spectrum modulation for unsurpassed EMC compliance. The devices are designed specifically for human interfaces, like control panels, appliances, gaming devices, lighting controls, or anywhere a mechanical switch or button may be found; they may also be used for some material sensing and control applications. These devices feature a SYNC pin which allows for synchronization with additional similar parts and/or to an external source to suppress interference.

  • QUANTUM RESEARCH GROUP QPROX QT310 DATA SHEET

    The QT310 is a single-channel digital advanced capacitance sensor IC that uses spread-spectrum burst modulation to dramatically reduce interference problems. It has full autocal capability, user programmable via cloning process, internal eeprom storage of user setups, cal data, variable drift compensation & recalibration times, BG and OBJ cal modes for learn-by-example, sync pins for daisy-chaining or noise suppression, variable gain via Cs capacitor change, selectable output polarity, high or low, toggle mode (optional via setups), push-pull output, completely programmable output behavior via cloning process from a PC and HeartBeat™ health indicator (can be disabled). It is widely used in material detection, toys and games, access controls, micro-switch replacement, appliance controls, security systems, fluid level sensors and industrial panels.

  • QUANTUM RESEARCH E6240 User Manual

    This document is the E6240 user manual, which introduces the overview of E6240, the setup and usage methods, QmBtn software, E6240 assembly details, and troubleshooting, etc.

  • QUANTUM E511 User Manual

    This manual introduces the E511 evaluation kit, including installation, usage, and troubleshooting

  • QUANTUM QT1081 handbook

    QT1081 8-KEY QTOUCH™ SENSOR IC is a touch sensor IC applied to touch panel. It supports 1 to 8 keys, has patented spread-spectrum charge-transfer technology, and can realize single-key mode. It supports 5mm x 5mm or larger key size, 6mm or wider key spacing, single layer electrode design, FR-4, CEM-1 or FR-2 PCB materials, Orgacon™ ink, plastic, glass, composite materials, painted surfaces, and adjacent ground metal. It supports a panel thickness of up to 50mm for glass and 20mm for plastic. The key sensitivity can be set by changing the value of the reference capacitor (Cs). It supports parallel discrete output, output voltage is 2.8V ~ 5.0V, and the working current is less than 15µA. The package form is 32-pin 5 x 5mm QFN, which meets the RoHS standard.

  • QUANTUM RESEARCH GROUP LQ QT60161B 16 KEY QMatrix KEYPANEL SENSOR IC Advanced second generation QMatrix controller Manual

    This document describes the features and characteristics of the LQ QT60161B 16 KEY QMatrix™ KEYPANEL SENSOR IC. The controller features an advanced second generation QMatrix controller, 16 touch keys through any dielectric, 100% autocal for life, SPI Slave or Master/Slave interface, parallel scan interface, adjustable sensitivity, response time, sleep mode, and more. It is suitable for applications such as automotive panels, machine tools, ATM machines, touch-screens, appliance controls, outdoor keypads, security keypanels, and industrial keyboards.

  • QUANTUM E411 user manual

    This is the user manual for QT411-ISSG QSlide™ IC evaluation and development application

Which document do I need?

User Manual

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in Quantum manuals

How much can the DXi3500 reduce disk capacity with de‑duplication?

It can decrease disk requirements by 90% or more.

From: Quantum DXi3500 Product Leaflet

What is the maximum number of virtual tape drives supported?

The appliance supports up to 64 virtual tape drives.

From: Quantum DXi3500 Product Leaflet

Does the DXi6500 support VMware environments?

Yes, it includes Quantum esXpress backup software designed for VMware.

From: Quantum DXi6500 Network Attached Disk Backup Appliance Product Leaflet

What network interfaces are available on the DXi6500?

The system supports up to six 1 GbE ports and up to two 10 GbE CX4 ports; higher models add two 8 Gb FC ports for direct tape routing.

From: Quantum DXi6500 Network Attached Disk Backup Appliance Product Leaflet

What does the safety symbol "危陰" mean?

It indicates a potential hazard that could cause personal injury if the safety instructions are not followed.

From: Schneider Electric Quantum 140 EHC 105 00 High Speed Counter Module User Manual

How are output signals set for the EHC 105 00 module?

Output signals are programmed by writing values to specific registers, for example OUT1="1", OUT2="0", etc.

From: Schneider Electric Quantum 140 EHC 105 00 High Speed Counter Module User Manual
