Featured A.R.D. Engineering manuals
A.R.D. Engineering Honda 750 Magneto Installation Instructions
This document provides step-by-step installation instructions for an A.R.D. Engineering magneto system manufactured exclusively for Honda 750 machines. The guide emphasizes precise timing settings derived directly from the crankshaft to ensure flawless performance without drive chain errors.
The manual details procedures for removing engine covers, installing the stub shaft and housing, setting rotor alignment with specific stator marks, and routing the timing belt carefully to prevent damage. It also covers electrical connections, including grounding the mounting bracket, connecting blue wires to the coil, and wiring the yellow kill switch.
Covers: Installation Steps · Timing Setup · Wiring Connections · Maintenance Schedule · Safety Precautions
Latest A.R.D. Engineering manuals
A.R.D. Engineering Honda 750 Magneto Installation Instructions
Installation Guide 2 pages · 90 KB · ENInstallation instructions for the A.R.D. magneto designed specifically for Honda 750 engines, covering assembly, timing setup, and wiring.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in A.R.D. Engineering manuals
What is the standard timing setting for the magneto rotor?
The standard timing is set to 35 degrees.
From: A.R.D. Engineering Honda 750 Magneto Installation Instructions
What is the minimum required clearance between the stators and the magnetic rotor?
There must be at least .006 clearance between the stators and the magnetic rotor.
From: A.R.D. Engineering Honda 750 Magneto Installation Instructions
