Featured Current Monitor manuals
Sefram SP 295 / SP 296 AC Current Clamp Product Data Sheet
The SP 295 and SP 296 are flexible AC current clamps designed for industrial maintenance and failure diagnostics. They can measure currents from 30 A up to 3000 A and connect to any device with an AC voltage input, making them suitable for cramped environments where conventional clamps are impractical.
The clamps feature a TRMS accuracy of ±3 % full‑scale, a bandwidth of 45 Hz–500 Hz, and output voltages of 100 mV/A, 10 mV/A or 1 mV/A. They are powered by two 1.5 V AAA batteries, include a low‑battery LED indicator, and meet IEC 1010 safety ratings CAT IV 600 V and CAT III 1000 V. Dimensions, sensor lengths and loop diameters differ between the SP 295 and SP 296 models. This manual is written in French.
Covers: Specifications · Dimensions & Weight · Power Source · Operating Temperature · Safety Ratings · Warranty
ETCR 085K High-Precision Open/Close Leak Current Sensor User Manual
The ETCR 085K is a high‑precision open/close leak‑current sensor designed for power, communications, railway, oil‑field and other demanding environments. It measures AC leak current, total current, harmonic current, frequency, phase, power and energy with a four‑layer shielding design and waterproof protection.
The manual provides an introduction, technical specifications, principle of operation, installation directions, wiring details, safety standards and handling instructions. It also includes dimensions, environmental limits and recommended installation methods for wall‑mount or direct‑mount on flat‑steel grounding conductors. This manual is written in Chinese.
Covers: Introduction · Technical Specifications · Principle and Structure · Installation Directions · Safety Standards
Honeywell CSDA/CSDC Series Switch Current Sensor Manual
The CSDA/CSDC series are digital switch current sensors that can measure both DC and AC current with high precision and low cost. They operate over a wide temperature range and provide a 20 mA output signal.
The document lists the various model variants (e.g., CSDA1BA, CSDC1BC) with their electrical ranges and includes contact information for Honeywell sales offices in Shanghai, Beijing, and other locations. This manual is written in Japanese.
Covers: Features · Specifications · Model Variants · Installation Guidelines · Contact Information
LEM AHR-B5 AC/DC Current Transducer Manual
The AHR‑B5 is an AC/DC current transducer that delivers a 0‑5 V analog output proportional to the measured current. It offers complete electrical isolation between primary and secondary circuits, no insertion loss, and easy mounting, making it suitable for monitoring motor and power‑supply currents with high accuracy.
The manual includes detailed electrical data, performance characteristics, safety and warning notes, isolation and transfer specifications, mechanical dimensions, and recommended installation procedures. It also lists the environmental limits, protection rating (IP20), and recommended torque for mounting screws. This manual is written in Japanese.
Covers: Electrical Data · Performance Data · General Data · Safety and Warning Notes · Isolation Characteristics · Transfer Characteristics
Latest Current Monitor manuals
Sefram SP 295 / SP 296 AC Current Clamp Product Data Sheet
Product Leaflet 1 pages · 286 KB · FRThe Sefram SP 295 and SP 296 AC current clamps measure up to 3000 A, offering CAT IV 600 V / CAT III 1000 V safety and flexible sensor lengths for tight spaces.
ETCR 085K High-Precision Open/Close Leak Current Sensor User Manual
User Manual 2 pages · 321 KB · ZHThe ETCR 085K user manual describes the high‑precision open/close leak current sensor, its specifications, installation, and operation.
Linear LT3905 Current Monitor
The document introduces the characteristics of the LT3905, including its working principle, application scenarios, advantages and disadvantages.
Honeywell CSDA/CSDC Series Switch Current Sensor Manual
User Manual 1 pages · 74 KB · JAManual for Honeywell CSDA/CSDC series switch current sensors, covering specifications, wiring, and operation.
LEM AHR-B5 AC/DC Current Transducer Manual
User Manual 4 pages · 688 KB · JAThe LEM AHR‑B5 manual provides specifications, safety instructions, installation dimensions, and electrical data for the AC/DC current transducer.
Honeywell CSDA/CSDC Series Switch Digital Current Sensor Product Data Sheet
Product Leaflet 1 pages · 76 KB · ZHHoneywell CSDA/CSDC series switch-type digital current sensors provide isolated digital output, fast 100 µs response, and low current loss.
LEM BLF-S7B Series Current Sensor Manual
User Manual 2 pages · 77 KB · ZHThe LEM BLF‑S7B series current sensor manual provides specifications, installation dimensions, and wiring information for the sensor.
CS600E2 Hall Current Sensor Manual
User Manual 2 pages · 147 KB · ZHThis manual provides specifications, wiring details, and usage instructions for the CS600E2 Hall current sensor.
TEFUL CS600N Hall Current Sensor Manual
User Manual 2 pages · 173 KB · ZHThe TEFUL CS600N Hall current sensor manual provides specifications, wiring details, and usage instructions for the CS600N series.
Tektronix TCP0150 Current Probe User Manual
User Manual 102 pages · 1.6 MB · ZHThe Tektronix TCP0150 User Manual provides setup, operation, safety, and maintenance instructions for the 20 MHz, 150 A AC/DC current probe.
BingZi HS02-P Series Current Sensor User Manual
User Manual 1 pages · 61 KB · ZHThe BingZi HS02-P series Hall‑effect current sensor manual details features, operating conditions, specifications, wiring and typical applications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Current Monitor manuals
What is the maximum current the SP 295 / SP 296 can measure?
The clamps can measure up to 3000 A, with selectable ranges of 30 A, 300 A and 3000 A.
From: Sefram SP 295 / SP 296 AC Current Clamp Product Data Sheet
Which safety categories does the clamp comply with?
It complies with IEC 1010 CAT IV 600 V and CAT III 1000 V safety standards.
From: Sefram SP 295 / SP 296 AC Current Clamp Product Data Sheet
What is the opening size of the ETCR 085K sensor?
The sensor’s opening size is 85 mm × 20 mm.
From: ETCR 085K High-Precision Open/Close Leak Current Sensor User Manual
How should the sensor be oriented during installation?
Mount the sensor with the P1 side facing up and parallel to the ground.
From: ETCR 085K High-Precision Open/Close Leak Current Sensor User Manual
What temperature range does the sensor operate in?
The sensor works from –25 °C up to 85 °C.
From: Honeywell CSDA/CSDC Series Switch Current Sensor Manual
Can the sensor measure both DC and AC current?
Yes, it can measure either DC or AC current.
From: Honeywell CSDA/CSDC Series Switch Current Sensor Manual
