Sunplus SPCE061A 16‑bit Single Chip Microcomputer Manual
This manual provides a detailed overview of the SPCE061A 16‑bit single‑chip microcomputer, including its CPU core, instruction set, memory organization, and hardware blocks such as A/D, D/A, UART and SIO. It also describes the development environment, C language programming, and integration of peripheral devices.
Additional sections cover interrupt handling, power management, and a range of application examples that illustrate how to use the device in embedded systems for electronics, automation and computer‑control projects. This manual is written in Chinese.
SunPlus SPCE061A specifications
| Flash memory | 32 KB |
|---|---|
| RAM | 2 KB |
| E² PROM | 8 KB |
Source: Sunplus SPCE061A 16‑bit Single Chip Microcomputer Manual
All SunPlus SPCE061A documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How much flash memory does the SPCE061A provide?
It provides 32 KB of flash memory for program storage.
From: Sunplus SPCE061A 16‑bit Single Chip Microcomputer Manual
What RAM size is available on the SPCE061A?
The device includes 2 KB of RAM.
From: Sunplus SPCE061A 16‑bit Single Chip Microcomputer Manual
What microcontroller does the SPCE061A experiment instrument use?
It uses the Sunplus SPCE061A 16‑bit SOC microcontroller.
What display is built into the instrument?
A back‑lit 128×64 dot‑matrix LCD driven by the SPLC501 chip.
What microcontroller does the experiment instrument use?
It uses the Sunplus SPCE061A 16‑bit SOC microcontroller as its CPU.
What display components are included?
It includes a back‑lit 128×64 LCD driven by SPLC501, a 4‑digit 7‑segment display, and eight LED indicators.
