Start here
Karcher BR/BD 530 and BR/BD 530 XL User Manual
This manual covers safety information, equipment purpose, and proper usage of the Karcher BR/BD 530 and BR/BD 530 XL floor cleaning machines. It explains the machine structure, control panel functions, and preparation steps before operation, including installation of brushes, rollers, and water connections.
Detailed sections describe how to add detergent, adjust water flow, operate the machine on various floor types, and perform daily, monthly, and yearly maintenance. Technical specifications such as operation width, tank capacities, and maximum slope are also provided. This manual is written in Chinese.
KARCHER BD530 specifications
| Nominal Voltage | 12 V |
|---|---|
| Capacity | 80 Ah |
| Capacity | 75 Ah |
| Capacity | 70 Ah |
| Dimensions (XL model) | 460 mm × 530 mm |
All KARCHER BD530 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the nominal voltage of the BR/BD 530 battery packs?
All BR/BD 530 battery packs have a nominal voltage of 12 V.
What capacities are available for the BR/BD 530 series batteries?
The series is offered in 70 Ah, 75 Ah, and 80 Ah capacities.
What is the maximum slope the equipment can operate on?
The machine can be used on slopes up to 2 %.
