Key facts
- Brand
- Cisco
- Model
- Catalyst 2918
- Category
- Other network devices
- Industry
- Computers
- Documents
- 2
- Languages
- ZH
- Last added
- 2026-09-29
Start here
Cisco Catalyst 2918 Switch Quick Start Guide
The guide walks you through unpacking the Catalyst 2918 switch, preparing the required tools, and connecting the power and console cables. It then explains the Quick Setup process, which assigns an initial IP address so the switch can be accessed from a PC.
Additional sections cover resetting the switch, accessing online documentation, and details about hardware warranty, FCC compliance, and support resources. The document is intended for network administrators performing first‑time installation and basic configuration. This manual is written in Chinese.
Cisco Catalyst 2918 specifications
| Operating Temperature | 32 °F – 113 °F (0 °C – 45 °C) |
|---|---|
| Storage Temperature | -13 °F – 158 °F (-25 °C – 70 °C) |
| Relative Humidity | 10 % – 85 % (non‑condensing) |
| Power Input | 100 V‑240 V AC, 1.3 A‑0.8 A, 30 W |
| Weight | 8 lb (3.63 kg) |
Source: Cisco Catalyst 2918 Switch Hardware Installation Guide
All Cisco Catalyst 2918 documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What is the maximum cable length for 10/100/1000 ports?
Cable length must not exceed 328 feet (100 meters) between the switch and the connected device.
From: Cisco Catalyst 2918 Switch Hardware Installation Guide
What are the operating temperature limits for the Catalyst 2918?
The switch can operate between 32 °F and 113 °F (0 °C to 45 °C).
From: Cisco Catalyst 2918 Switch Hardware Installation Guide
How do I reset the Catalyst 2918 switch?
Press and hold the mode button for about 3 seconds until the LEDs start flashing, continue holding for another 7 seconds until they stop, then the switch will reboot.
What must be true before starting Quick Setup?
No devices should be connected to the switch because it acts as a DHCP server during Quick Setup.
