ZTE DCRS-6512 12-Slot Chassis Layer 3 Switch Hardware Installation and Maintenance Manual

About this manual

The document serves as a hardware installation and maintenance guide for the ZTE DCRS-6512, a high-performance network device designed for small to medium-sized enterprise core networks. It details the physical description of the chassis, including fan trays, power supply modules, and management interfaces. This manual is written in Chinese.

What's inside

• Installation Steps
• Product Overview
• Chassis Description
• Power Supply Module
• Fan Tray
• Network Management Module
• Interface Modules
• Safety Information

Frequently asked questions

What is the minimum hardware requirement for DCRS-6512 to operate normally?

The minimum requirements include 2 fan trays (4 fans), 1 power supply module, 1 network management module with software, and interface modules as needed.

How long does the initialization process take after powering on?

The initialization process takes approximately 5 minutes to complete before the switch can begin working.

Does the DCRS-6512 have a physical power button?

No, the switch does not have an on/off button; it powers on automatically when connected to a power source.
