The XL7005A datasheet from Xinlong Semiconductor details specifications, input range, switching frequency, current, package and performance of this…
The XL7005A is a high‑voltage buck (step‑down) DC‑DC converter designed for portable, mobile and automotive devices. It supports a wide input voltage range and is suitable for battery‑powered applications such as 12 V‑48 V systems.
Key specifications include a 5 V‑100 V input range, 150 kHz switching frequency, 0.4 A switch current, adjustable 1.25 V output, SOP8‑EP package and up to 5 W output power. The datasheet also lists related product families and contact information for Xinlong Semiconductor. This manual is written in Chinese.
| Input voltage range | 5 V ~ 100 V |
|---|---|
| Switching frequency | 150 kHz |
| Output voltage version | ADJ (1.25 V) |
| Package type | SOP8‑EP |
| Maximum output power | 0 ~ 5 W |
The XL7005A operates with an input voltage from 5 V to 100 V.
It uses a switching frequency of 150 kHz.
The chip is packaged in an SOP8‑EP surface‑mount package.
The device can deliver up to 5 W of output power.
