The Xiaobai Q1 Smart Panoramic Camera User Manual provides product overview, installation methods, connection setup, features, specifications, and usage…
This manual introduces the Xiaobai Q1 smart panoramic camera, its components, and key specifications such as resolution, lens angle, and IP66 waterproof rating. It explains the three mounting options—wall, ceiling, and enclosure—and provides step‑by‑step instructions for each method.
The guide also covers connection settings, including power supply, MicroSD card installation, factory reset, and integration with the Mi Home app. Additional sections describe night‑vision capabilities, video sharing, safety precautions, and after‑sales service policies. This manual is written in Chinese.
| Power input | 12V 1A |
|---|---|
| Resolution | 2304×1296 |
| Lens angle | 95° |
| Working temperature | -30°C ~ 60°C |
| Wi‑Fi | IEEE 802.11 b/g/n 2.4GHz |
| Waterproof rating | IP66 |
| Dimensions | 139 × 128 × 135 mm |
| Net weight | 618 g |
| Video codec | H.265 |
| Maximum MicroSD capacity | 256 GB |
Press and hold the reset button for a few seconds; the device will restore factory defaults while keeping any MicroSD data intact.
The camera supports MicroSD cards up to 256 GB in capacity.
