This manual describes the Wi‑Tek WI‑PMS310GF‑UPS 8‑GE+2‑SFP Solar UPS Managed PoE Switch. It covers the hardware specifications, power‑over‑Ethernet capabilities, solar and battery backup features, and the web‑based management interface.
The document walks the user through web access, login procedures, navigation of the configuration pages, and detailed settings for ports, VLANs, SNMP, QoS, ACLs, PoE, clustering, ERPS, and log management, enabling full control of the switch in a network environment.
| RJ45 ports | 8 10/100/1000Mbps |
|---|---|
| SFP slots | 2 1000Mbps |
| Maximum PoE power | 150 W total on 8 ports |
| Power consumption (max) | 150 W |
| Power supply input | AC 110‑250 V 50/60 Hz |
| Solar controller input | 24 V, 500 W max |
| Battery input | 24 V, 100 AH max |
| Operating temperature | -20 °C to +60 °C |
| Dimensions | 225 mm × 105 mm × 32 mm (L×W×H) |
| Packet forwarding rate | 14.9 Mpps |
The switch can deliver up to 150 W of continuous PoE power across its eight PoE ports.
A CPU of Pentium 586 or higher, at least 128 MB RAM, 800×600 screen resolution, 256 colors, and a browser such as IE 4.0 or Netscape 4.01.
The switch provides two 1000 Mbps SFP slots for fiber connections.
