The Welzek K6206 is a high‑precision, dual‑channel, LAN‑controlled power supply with up to 36 W output, fan‑less design and compact size.
The K6206 is a high‑precision direct‑flow control power supply aimed at mobile‑phone testing. It provides two independent DC output channels that can be operated in either dual‑channel or single‑channel mode, all controlled via Ethernet commands compatible with existing test software. The unit integrates two 4‑port switches, a touch‑screen interface, and a fan‑less aluminum chassis for low noise and power consumption.
Technical specifications include a voltage range of 0‑6 V, current up to 3 A per channel (peak 5 A), maximum power 36 W, programming accuracy ±0.05 % + 5 mV, bandwidth 20 Hz‑20 MHz, and a transient response time of 150 µs. The device measures 180 × 44.45 × 252 mm and weighs 2.2 kg, making it compact for test platforms. This manual is written in Chinese.
| Output Voltage Range | 0–6 V |
|---|---|
| Output Current per Channel | 0–3 A (peak 5 A) |
| Maximum Power | 36 W |
| Programming Accuracy | ±0.05 % + 5 mV |
| Bandwidth | 20 Hz – 20 MHz |
The K6206 provides two independent DC output channels.
The unit can deliver up to 36 W of power.
The transient response time is 150 µs.
