The WELLON programmer manual explains hardware features, system requirements, installation, programming, testing and troubleshooting for multiple models.
This manual covers the WELLON series of universal device programmers, including models GP800, GP600, VP998, ISP200, ISP208, AUTO300, VP798, VP598, VP398S, VP299 and SP108. It describes the hardware configuration, supported device packages, and the software interface that runs on Windows 7/10.
Installation steps, programming procedures, mass‑production mode, testing functions, error handling and warranty information are provided, along with a help section and customer‑support contacts.
| ZIF socket pins | 48‑pin or 40‑pin |
|---|---|
| Supported DIP packages | 8‑pin to 48‑pin |
| Operating system | Windows 7 / Windows 10 |
| Minimum CPU | Pentium or compatible |
| Minimum RAM | 512 MB |
| Free hard‑disk space | 100 MB |
Insert the installation CD, run the setup to install the software, then the USB driver is installed automatically; if not, locate it in C:\\weilei\\WELLON\\usbsys or C:\\weilei\\WELLON\\usbsys64.
Run the reset utility located at c:\\weilei\\wellon\\wellon_reset.exe, then restart the programmer.
Select the device, enable Edit Auto, set the desired operation (e.g., Auto Program, Verify), enable Target Count, then press Prog; the programmer will automatically program each chip placed in the socket.
