This manual provides operating instructions, safety guidelines, and maintenance procedures for the Wavetek MSQ-800 Signal Analyzer used in TV and broadcast…
The Wavetek MSQ-800 is a field test instrument designed to measure analog and digital channel levels, as well as DVB-C QAM modulation parameters like MER and BER. It supports both laboratory use with external power and field operations using batteries or vehicle power sources.
This user manual covers the device's design, functions, and basic operating procedures. Key topics include safety precautions, control panel descriptions, various measurement modes (level, scan, tilt, MER/BER), automatic testing features via AutoPlan™, battery management, maintenance steps, troubleshooting guides, and environmental specifications for storage and operation. This manual is written in Chinese.
| Operating Temperature (Normal) | 23±5°C |
|---|---|
| Storage Temperature | -20 to 40°C (-4 to 104°F) |
| Relative Humidity (Storage) | Not higher than 90% at 30°C |
| Battery Type | NiMH, AA batteries (4 included) |
Yes, it can operate using batteries or a vehicle cigarette lighter power socket.
Check the status and connect the main power adapter; low voltage or a faulty battery may be the cause.
Press and hold the Power button for 5 seconds to turn off the device, then release and power it on again.
