VHS VHS40/VHS50 3‑Way Residual Pressure Release Valve User Manual

User manual for the VHS 3‑way residual pressure release valve covering safety, installation, operation and specifications.

VHS VHS40/VHS50 3‑Way Residual Pressure Release Valve User Manual - cover page
Brand
*VHS40*
Category
Industrial Supply
Document type
User Manual
Language
Chinese
Pages
7
File format
PDF
File size
124 KB
Updated
06 October, 2026
MD5 checksum
78E9E2435943CF53872CF97852FD5126
PDF
VHS VHS40/VHS50 3‑Way Residual Pressure Release Valve User Manual PDF

About this manual

This manual provides safety precautions, installation requirements and operating instructions for the VHS 3‑way residual pressure release valve (models VHS40 and VHS50). It explains how to properly connect the valve, adjust settings, and perform routine checks to ensure reliable pressure release.

Technical data such as inlet/outlet sizes, pressure and temperature ranges, and material specifications are listed, along with maintenance guidelines and troubleshooting tips. This manual is written in Chinese.

What's inside

  • Safety Precautions
  • Installation Requirements
  • Operation Instructions
  • Technical Specifications
  • Maintenance and Troubleshooting

Specifications

Pressure Range0.1 – 1.0 MPa
MaterialISO VG32

Frequently asked questions

What pressure range can the valve handle?

The valve operates between 0.1 MPa and 1.0 MPa.

What are the available inlet/outlet sizes?

The valve is offered with 1/4, 3/8, 1/2 and 3/4 inch connections.
