User manual for the VCAM DW800 series universal automatic solder paste dispenser, covering safety, setup, operation, maintenance and troubleshooting.
This manual provides the necessary information to safely install, configure, and operate the VCAM DW800 series universal automatic solder paste dispenser. It includes a preface, safety precautions, technical specifications, step‑by‑step operating instructions, parameter settings, and maintenance procedures.
Additional sections cover routine maintenance, fault diagnosis, warranty records, and contact information for service support. This manual is written in Chinese.
| Power Supply | AC220~240V |
|---|---|
| Plug | 10A‑3 pin (national standard) |
| Power Consumption | ≤100 W |
| Operating Temperature | 10 °C – 50 °C |
| Operating Humidity | 10 % – 60 % RH |
The minimum setting is 5 g, and the amount can be increased in 5 g steps up to a maximum of 40 g.
