This manual provides operating instructions, parameter settings, and port descriptions for the UT-3 W500 Auto-Trimmer Servo Motor System.
This manual serves as a reference guide for the UT-3 W500 Auto-Trimmer Servo Motor System, covering the introduction to the servo system, common display screen operations, and safety requirements. It details how to enter and modify system and user parameters, including specific functions like auto-trimming, auto-foot lifter, and multi-part sewing modes.
The document also includes a comprehensive table of operating parameters with default values and ranges, descriptions of control box ports for connecting devices like solenoids and governors, and an analysis of error codes. It concludes with a packing list and warranty policy information. This manual is written in Chinese.
| Supply Voltage | 210V ~ 240V |
|---|---|
| Warranty Period | 2 years free warranty, Lifetime Maintenance |
| System Password | 2014 |
| Presser Foot Control Voltage | 30V |
The default system password is 2014.
The presser foot control port connects to a solenoid or solenoid valve operating at 30V.
