UniStrong UPK100 Airborne GNSS Receiver User Manual

About this manual

The UniStrong UPK100 is an airborne high-precision GNSS receiver designed for the UAV industry, specifically for surveying and mapping. It features a built-in V28 board and supports multiple satellite systems including GPS, GLONASS, BeiDou, Galileo, QZSS, and SBAS. The device is capable of receiving positioning data and synchronizing camera shutter exposure for post-processing solutions, helping to reduce the need for ground control points in UAV surveying operations.

The manual provides instructions on product composition, installation steps, and the use of the Web User Interface (WebUI). Users can configure settings such as APN, working modes, COM ports, coordinate transformations, and satellite systems via the WebUI. The document also details the DB15 interface definitions and includes important precautions for device configuration and data processing. This manual is written in Chinese.

What's inside

• Welcome to UPK100
• Technical Specifications
• Product Composition
• Installation
• Web Access Introduction
• Satellite Information
• Device Settings
• NMEA Customization
• Other Settings
• Precautions

Specifications

Frequently asked questions

What is the UPK100 receiver designed for?

It is a airborne GNSS receiver designed for the drone industry, primarily used in drone surveying to receive positioning data and synchronize camera shutter exposure.

What is the input voltage range for the device?

The device accepts an input voltage of 5-36V DC.

What is the default login password for the UPK100 web interface?

The default password is password.
