This manual provides operation, installation, safety and maintenance instructions for the TOOCEN Turret Full Servo Series robot arm.
The document outlines safety precautions and operational guidelines for the turret‑type full‑servo robot arm used with horizontal injection molding machines. It details installation dimensions, protective zones, noise testing, and the required electrical and pneumatic connections.
Further sections cover pre‑start setup, speed adjustments, vacuum generator maintenance, routine lubrication, and a complete pneumatic circuit diagram with part numbers. Warranty terms and non‑warranty conditions are also specified. This manual is written in Chinese.
| Operating Air Pressure | 0.5 MPa (5 kgf/cm²) |
|---|---|
| Design Life | 5–10 years |
Lubrication is required approximately every 50,000 cycles or about once a month, using the specified grease or oil.
