The TOKY AI208X Temperature Controller User Manual provides installation, wiring, operation, alarm and PID tuning instructions.
This manual covers the AI208X series temperature controller, detailing dimensions, environmental limits, power requirements, and safety standards. It includes model illustrations, connection diagrams, and a full description of the menu system.
Operational guidance explains how to use the RUN/STOP function, configure alarm outputs, select SSR or relay output, and perform PID auto‑tuning. Installation steps describe mounting the unit and fixing brackets, while the specifications section lists electrical parameters and performance data. This manual is written in Chinese.
| Power supply | AC/DC 100 ~ 240 V |
|---|---|
| Relay capacity | AC 250 V / 3 A |
| Sample rate | 2 times per second |
| Storage environment | -10 ~ 60 °C, no condensation |
| Weight | About 400 g |
| Dimensions (model 4) | 48 W × 48 H × 73 L mm |
Press and hold the “R/S” key for more than 3 seconds to enter STOP mode.
The controller operates from an AC or DC supply of 100 ~ 240 V.
Yes, the output type (SSR or relay) is selected in the ACT menu.
