This reference guide details TE Connectivity's aluminum shear bolt splice connectors, covering features, applications, benefits, and specifications for…
This document serves as a reference guide for TE Connectivity's aluminum shear bolt connectors, detailing their features, applications, benefits, and specifications. It covers a range of models including ASBS and ASBR series, designed for heavy-duty utility applications.
| Electrical Requirements | Class A of ANSI C119.4 |
|---|---|
| Mechanical Requirements | Exceeds Class 3 connector |
| Primary Application | Underground splices up to 35 kV |
| Conductor Range | #2 AWG compact to 1000 kcmil |
| Material | Tin-plated aluminum alloy |
They meet Class A electrical requirements, exceed Class 3 mechanical requirements, and feature a solid center stop to eliminate oil leakage.
Yes, they are dual rated for both aluminum and copper conductors.
