T&T Quick Change Cartridge B&B Type Parts List

About this manual

This document provides a detailed catalogue of parts for the T&T Quick Change Cartridge B&B Type, covering several configurations for Emhart IS machines, including horse‑shoe type plunger adapters and plunger adapters with clamp rings.

Each entry lists an item number, part number, and a brief description, allowing users to identify and order the correct components for their cartridge assemblies.

What's inside

• Cartridge Catalogue Version 9 -2018
• QUICK CHANGE CARTRIDGE B&B TYPE – DG 4 1/4", DG 5 ", TG 4 1/4" for Emhart IS machine horse shoe type plunger adapter
• QUICK CHANGE CARTRIDGE B&B TYPE – DG 4 1/4", DG 5 ", TG 4 1/4" for Emhart IS machine plunger adapter with clamp ring
• QUICK CHANGE CARTRIDGE B&B TYPE – DG 5 1/2 ", DG 6 1/4 ", SG 5 1/2 " for Emhart IS machine horse shoe type plunger adapter
• QUICK CHANGE CARTRIDGE B&B TYPE – DG 5 1/2 ", DG 6 1/4 ", SG 5 1/2 " for Emhart IS machine plunger adapter with clamp ring

Specifications

Frequently asked questions

What is the part number for the cover ring?

The cover ring is part number T90000012.

Which part number corresponds to the lock screw?

The lock screw part number is T90003169.

What part number is used for the plunger adapter in the horse‑shoe type configuration?

The plunger adapter part number is T90003180.
