The Studiologic MP-113/MP-117 Pedalboard User Manual provides safety instructions, setup, operation, and specifications.
The MP Pedalboard is a professional MIDI controller with 13 (MP‑113) or 17 (MP‑117) dynamic keys, a numeric keypad, and dedicated panel buttons for MIDI channel, program change, bank select and transpose. It lets musicians trigger MIDI events by foot for both bass lines and other MIDI‑controlled devices.
The manual covers safety warnings, first‑time setup, detailed operating methods, function descriptions, technical specifications, and regulatory declarations. It also explains how to store custom settings and how to power the unit with the supplied 100‑240 VAC adapter delivering 9 V 1 A.
| Number of Keys | 13 / 17 |
|---|---|
| Volume (default) | 127 (not editable) |
| Pitch Bend (default) | 64 (not editable) |
| MIDI Channel (default) | 1 |
| Power Supply | DC IN 9 V – 1 A |
| Adapter Input/Output | 100‑240 V input, 9 V 1 A output |
| Weight | 7.5 kg / 16.5 lb |
Hold the MIDI CHANNEL button and enter the desired channel number using the numeric keypad, then release the button.
Press BANK SELECT and PROGRAM CHANGE simultaneously for at least three seconds; the settings are saved in internal memory.
Use the supplied power adapter; the unit accepts 100‑240 VAC input and provides a 9 V 1 A DC output.
