The SRDIT IPAM4800 DSLAM product leaflet details its 24‑port ADSL/ADSL2+/G.SHDSL access, interfaces, management options, and technical specifications.
The IPAM4800 is a compact 1U DSLAM designed for small‑capacity rural and suburban sites. It offers 24 ports of ADSL/ADSL2+/G.SHDSL access, up to 26 Mbps bandwidth and a transmission distance of over 6 km, with built‑in voice separation and extensive QoS features.
The device provides multiple network uplink options (100Base‑T, optional 100Base‑FX, optional E1), RJ21 voice/data cable interface, and a console port for local maintenance. Management can be performed via SNMP, console, web, Telnet, Bootp or web upgrade, and it supports a wide range of protocols such as VLAN, MAC/IP binding, NAT, DHCP, IGMP snooping, PPPoE/PPPoA, and traffic‑congestion control. Power options include 220 V AC (47‑63 Hz) or –48 V DC with consumption under 40 W. This manual is written in Chinese.
| Ports | 24 ADSL2+/SHDSL ports |
|---|---|
| Maximum bandwidth | 26 Mbps |
| Maximum transmission distance | over 6 km |
| Built‑in voice separator | Yes |
| Power supply | 220 V AC 47‑63 Hz or –48 V DC, <40 W |
| Dimensions | 483×320×44.5 mm (1U, 19‑inch) |
It provides 24 ports for ADSL2+/SHDSL user access.
The device can transmit up to 26 Mbps.
It supports 220 V AC (47‑63 Hz) or –48 V DC power supplies, with power consumption under 40 W.
