Installation guide for the Sony 1600TV Lines high‑resolution color CCTV camera with setup, safety and configuration instructions.
This manual provides safety precautions, installation steps, and detailed configuration for the Sony 1600TV Lines Super High Resolution Color Camera. It covers power requirements, mounting, cleaning, and handling instructions to ensure reliable operation in CCTV and security surveillance applications.
The guide also explains the on‑screen display (OSD) menu, including exposure, color, day/night, special settings, motion detection, and privacy zones. Technical specifications such as sensor type, resolution, illumination, and video output are listed for reference.
| Power source | AC24V ± 10% / DC12V ± 10% |
|---|---|
| Maximum power consumption | 4.0 Watts |
| Image sensor | 1/3" SONY Super‑HAD CCD |
| Resolution | 600 TVL (colour) |
| Minimum illumination (color) | 0.14 Lux |
The camera can be powered by either AC24V ± 10% or DC12V ± 10%.
The maximum power consumption is 4.0 Watts.
It uses a 1/3" SONY Super‑HAD CCD sensor.
The camera needs at least 0.14 Lux for colour images.
