The Slick 4300 Overhaul Manual provides detailed maintenance, disassembly, assembly, and troubleshooting procedures for the 4300 series aircraft magnetos.
This manual covers the complete overhaul process for Slick 4300 series magnetos, including step‑by‑step disassembly, inspection, part replacement, and reassembly. It also contains technical notes, safety guidelines, and troubleshooting information to ensure reliable operation.
Additional sections provide a glossary of terms, appendices with part numbers, and recommended tools such as the Slick T‑100 assembly and timing kit. The document follows FAA‑approved maintenance scopes and includes mandatory inspection intervals.
| Weight | 3.3–4 lbs |
|---|---|
| Impulse coupling inspection interval | Every 500 hours of operation |
The impulse coupling must be inspected every 500 hours of operation.
A Slick 4300 magneto weighs approximately 3.3 to 4 pounds.
The Slick T‑100 assembly and timing kit is strongly recommended for disassembly and assembly.
Slick magnetos are manufactured by Champion Aerospace.
