The SAC-16 alarm controller manual explains features, communication settings, wiring diagrams, and DIP switch configuration for the SAT-08 output module.
This manual describes the SAC-16 alarm controller, a 16‑zone alarm monitoring unit designed to work with the SAT‑08 output module. It details the controller's functions, system features, and how it integrates with SKY2004 security management software.
Technical information includes RS485 communication parameters, supported baud rates, DIP‑switch address and speed settings, and wiring diagrams for connecting the controller to network concentrators, output modules, and other controllers. This manual is written in Chinese.
| Alarm zones | 16 |
|---|---|
| Communication interface | RS485 |
| Transmission mode | Half‑duplex |
| Baud rates | 1200, 2400, 4800, 9600 bps |
| Transmission code | ASCII |
| Rack unit size | 1U |
The address is set with the six‑position DIP switch; bits 1‑4 select the device address according to the table in the manual.
The controller supports 1200, 2400, 4800, and 9600 bps, selectable via DIP switch bits 5‑6.
It uses a single RS485 interface for network and device connections.
The controller can monitor up to 16 independent alarm zones.
