The manual details specifications, dimensions, ratings, TCR values, packaging, marking codes, and usage guidelines for Shenzhen Sanye Yuan 0402-1206…
This document describes the general thick‑film chip resistor series produced by Shenzhen Sanye Yuan, covering sizes from 0402 to 1206. It highlights the miniature size, high reliability, low assembly cost, and compliance with RoHS and halogen‑free requirements.
The manual includes sections on features, type designation, construction, dimensions, derating curves, ratings, TCR values (standard and high‑precision), characteristics, recommended solder‑pad sizes, packaging, resistance‑value code tables, marking rules, usage instructions, and soldering recommendations. This manual is written in Chinese.
| Dimensions (0402) | L 1.00±0.10 mm, W 0.50±0.05 mm, t 0.35±0.05 mm |
|---|
