The Sharp AR‑B2201P‑B2202P Series monochrome laser single‑function printer user guide provides safety instructions, setup, operation, maintenance and…
This user guide covers safety precautions, unpacking, paper handling, driver installation for Windows and macOS, wireless network configuration, printing functions, control panel description, routine maintenance, and detailed troubleshooting for the Sharp AR‑B2201P‑B2202P Series printer.
Technical specifications such as processor speed, memory, power requirements, supported media, print speed and environmental limits are listed in the product specifications section. This manual is written in Chinese.
| Processor | 600 MHz |
|---|---|
| Memory | 128 MB |
| Power Supply | 220 V |
| Communication Interface | Hi‑Speed USB 2.0 |
| Operating Temperature | 10‑32 °C |
| Operating Humidity | 20‑80 % RH |
| Dimensions (W×D×H) | 337 mm × 220 mm × 178 mm |
| Weight (without toner) | 4 kg |
| Print Speed (A4) | 22 ppm |
| First‑Page Print Time | ≤ 7.8 s |
| Print Language | GDI |
| Maximum Print Size | Legal (216 mm × 355.6 mm) |
| Recommended Monthly Print Volume | 700 pages |
| Monthly Print Load | 15 000 pages |
| Paper Input Capacity | 150 sheets (80 g/m²) |
| Paper Output Capacity | 100 sheets (80 g/m²) |
| Supported Media Types | Ordinary, thin, thick paper, transparencies, card stock, labels, envelopes |
| Supported Media Sizes | A4, A5, JIS B5, ISO B5, A6, Letter, Legal, etc. |
Before cleaning, disconnect the power and avoid using wet hands or liquid cleaners; the printer contains high‑voltage components and a hot fusing unit.
Open the feed tray or rear access panel, gently remove any jammed paper, and ensure no torn pieces remain before restarting the printer.
The printer is designed for an ambient temperature of 10‑32 °C and a relative humidity of 20‑80 % RH.
Insert the supplied driver CD or run the downloaded installer, then follow the on‑screen prompts in the driver installation section.
