This manual provides specifications, installation steps, wiring diagrams, and troubleshooting for the CTLW series DC motor controllers.
The CTLW series DC motor controllers are described with their functional features, electrical parameters, and mechanical structure. The manual outlines the controller's operation, safety notes, and the range of models such as CTLW4824, CTLW4832, and others.
Detailed installation instructions, wiring diagrams, and debugging procedures are provided, including guidance for connecting J1, J2, and power terminals. Troubleshooting tips and adjustment methods help users achieve reliable performance in industrial applications. This manual is written in Chinese.
| PWM frequency | 15 KHz |
|---|---|
| Maximum output current | 100 mA |
| Supply voltage options | 48 V / 60 V / 72 V |
| Current rating options | 140 A / 200 A / 240 A / 300 A / 320 A / 370 A |
The PWM frequency is 15 KHz.
The controller supports 48 V, 60 V, and 72 V supply voltages.
Current ratings of 140 A, 200 A, 240 A, 300 A, 320 A, and 370 A are provided.
