User manual for the RUKING HERO series servo system covering installation, wiring, parameter setup, operation examples and fault handling.
This manual provides step‑by‑step guidance for inspecting, installing and wiring the RUKING HERO series servo drive and motor. It includes detailed parts lists, mounting dimensions, and environmental requirements to ensure safe and reliable operation.
The document also describes how to configure parameters, use common operation modes such as JOG and multi‑speed runs, and troubleshoot fault codes. Safety precautions, grounding instructions and maintenance tips are included to help users keep the system in optimal condition. This manual is written in Chinese.
| Motor capacity (kW) | 0.2–1.5 |
|---|---|
| Input voltage | 200‑240 V AC, 50/60 Hz |
| Continuous output current | 2.1–9.1 A |
| Peak instantaneous output current | 6.3–27.3 A |
| Protection IP rating | IP00 (open) |
| Control mode | Position control |
| Operating temperature | 0 °C to +55 °C (storage –20 °C to +70 °C) |
| Weight | 1.0–1.5 kg |
Er831 means instantaneous current is too high, exceeding the allowed limit in the inverter, and the drive shuts down.
Select the alarm clear operation from the panel menu to reset the alarm condition.
The grounding system must be properly implemented according to current national electrical regulations.
