The Quantum Data 980 HDMI Protocol Analyzer Module manual details features, specifications, and operation for HDMI and MHL signal analysis.
This manual describes the Quantum Data 980 HDMI Protocol Analyzer Module, a device for analyzing HDMI 1.4b and MHL signals. It covers key features, connector functions, and compliance test sections for both source and sink configurations.
The document provides detailed specifications such as TMDS rates, memory size, physical dimensions, and environmental limits, as well as instructions for using the built‑in Ethernet GUI manager and external trigger inputs.
| Pixel/TMDS Rate | 297 MHz (2.97 Gb/s per pair) |
|---|---|
| Memory Size | 2 GB |
| Physical Size (H × D × W) | 241.3 mm × 292.1 mm × 279.4 mm |
| Weight | 7.5 kg |
| Operating Temperature | 0 °C to 40 °C |
| Video Encoding | RGB, YCbCr (4:4:4 or 4:2:2) |
| Bits per Component | 24/30/36‑bit RGB or YCbCr |
The HDMI Rx input supports a TMDS rate up to 297 MHz (2.97 Gb/s per pair).
The module includes 2 GB of memory.
It operates from 0 °C to 40 °C.
