Pro-Log Series 7000 STD BUS Technical Manual and Product Catalog

Technical manual and catalog for Pro-Log's Series 7000 STD BUS, detailing specifications, pinouts, and compatible cards.


Pro-Log Series 7000 STD BUS Technical Manual and Product Catalog - cover page
Brand
Pro-Log
Category
Industrial Supply
Document type
User Manual
Language
English
Pages
157
File format
PDF
File size
43.3 MB
Published
03 October, 2026
Updated
03 October, 2026
MD5 checksum
6535A1598DE0D0CB28AA5C93A52E93F6

About this manual

The Pro-Log Series 7000 STD BUS manual provides design engineers with the complete electrical, mechanical, and functional specifications of the 56‑pin, 8‑bit microprocessor bus system. It defines the standard pinout, power distribution, and signal definitions, and includes data sheets for each card family.

The document also catalogs the Series 7000 product line, describing motherboards, interconnect cables, and various I/O and processor cards, along with their mechanical dimensions and environmental ratings.

What's inside

  • STD BUS Specification
  • STD BUS Practice
  • STD 7000 Specifications
  • STD 7000 Data Sheets
  • Motherboards
  • Interconnect Cables
  • Electrical & Mechanical Specifications

Specifications

Connector type56‑pin edge connector
Card size4.5 × 6.5 in (114.30 × 165.10 mm)
Logic power voltage+5 VDC
Auxiliary power voltage+12 VDC
Data bus width8‑bit bidirectional
Address bus width16‑bit

Frequently asked questions

What is the pin count of the STD BUS connector?

The STD BUS uses a 56‑pin edge connector.

What is the standard card size for Series 7000 modules?

Cards are 4.5 × 6.5 in (114.30 × 165.10 mm).
