The PRIMRON 5809 is a 24‑needle industrial dot‑matrix printer offering up to 900 cps speed, low 54 dBA noise, multi‑language interface and multiple…
The PRIMRON 5809 is a heavy‑duty 24‑needle dot‑matrix printer designed for industrial use. It delivers a maximum printing speed of 900 characters per second at 10 CPI, with a very low noise level of 54 dBA and a long‑lasting print head rated for 800 million characters.
Standard interfaces include parallel, serial, USB 2.0 and Ethernet, and the printer supports a wide range of media widths (76‑432 mm) and up to eight‑copy forms. Optional dual paper trays and remote management software provide high automation and easy IT administration. This manual is written in Chinese.
| Maximum printing speed | 900 cps @10 CPI |
|---|---|
| Noise level | 54 dBA |
| Print head lifetime | 800 million characters |
| Ribbon life | 25 million characters |
| Standard interfaces | Parallel, Serial, USB 2.0, Ethernet |
| Dimensions (L×W×H) | 450 × 700 × 320 mm |
| Weight | 21 kg |
It can print up to 900 characters per second at 10 CPI.
The printer includes parallel, serial, USB 2.0 and Ethernet ports as standard.
Its noise level is as low as 54 dBA, about 50 % quieter than comparable models.
