The manual provides setup, installation, power, and peripheral connection instructions for the Powerleader NET-911 industrial server.
The Powerleader NET-911 industrial server manual outlines safety notices, warranty information, and support channels, stressing proper handling of the shipped unit, inspection of packaging, and that only qualified personnel should open the chassis.
It details installation‑location requirements, power‑line specifications, how to check and replace power cables, procedures for adding internal devices, and step‑by‑step peripheral connections (mouse, keyboard, monitor, printer, modem, network cable). The document also includes a board layout diagram and definitions of the various interface pins. This manual is written in Chinese.
| Board size | 203 mm × 146 mm (5.25 in) |
|---|---|
| CPU | Atom230 (non‑upgradeable) |
| Chipset | Intel 945GC Express (Northbridge) / ICH7 (Southbridge) |
| Memory | DDR2 400/533/667 SDRAM, up to 2 GB, 1 DIMM slot (240‑pin, 1.8 V) |
| Power socket | Three‑pin power socket, overload 13 A, load ≥7 A |
| Power cable length | Maximum 4.5 m, flexible VDE‑certified cable |
It requires a three‑pin power socket that meets local standards, with an overload rating of 13 A and a load current not less than 7 A.
The server has one DDR2 DIMM slot (240‑pin, 1.8 V) supporting up to 2 GB of memory.
No, the front panel power switch cannot cut AC voltage; the power must be disconnected by unplugging the power cable.
