A quick reference guide for perma STAR VARIO mounting systems, detailing brackets, kits, attachment methods, and part numbers.
The perma STAR VARIO Quick Reference Pocket Guide provides concise information on the mounting systems used with STAR VARIO lubricators. It lists part numbers, explains the digit coding system, and describes the various bracket and kit configurations.
The guide covers standard‑duty, heavy‑duty, cage, and rail brackets, as well as special‑purpose options and pre‑assembled grease lines. Each section includes example kits with the components required for installation, such as beam clamps, covers, elbows, reducers, and grease lines.
| Bracket material | Stainless steel |
|---|---|
| Standard duty bracket attachment options | BC30 or BC65 |
| Recommended grease line internal diameter | 3/8" |
The first digit denotes part type (M = Mount, K = Kit), the second digit indicates the number of lubricator points, and the third and fourth digits specify the attachment type such as 30mm beam clamps or cage hooks.
The three most common attachment methods are 30 mm beam clamps, 65 mm beam clamps, and cage hooks.
Perma recommends grease lines with a 3/8 inch internal diameter.
