Installation guide for Percherry 360° panoramic dash cam, covering system components, mounting, wiring, and safety precautions.
This manual provides step‑by‑step instructions for installing the Percherry 360° panoramic dash cam system. It describes the overall system architecture, including the main unit and four wide‑angle cameras (front, rear, left, right), as well as the required wiring harnesses and accessories.
The guide details safety precautions, proper placement of the main unit, mounting methods for each camera, wiring routes, and connection procedures. It emphasizes that installation must be performed by authorized personnel or a professional service center to avoid damage or safety hazards. This manual is written in Chinese.
| Output voltage | 3.3V |
|---|---|
| Micro SD card slot purpose | System upgrade |
| DIP switch functions | Left: PAL/NTSC video output; Right: normal/upgrade mode |
| Number of cameras | 4 (front, rear, left, right) |
| Connection type | Wired transmission to main unit |
Installation must be carried out by authorized personnel of the company or professional technicians from a local service center.
The main unit provides an external output voltage of 3.3 V for powering the cameras.
The system includes four wide‑angle cameras positioned at the front, rear, left and right of the vehicle.
No. Directly connecting the cameras to power without the supplied harness will damage the cameras.
