User manual for the KG316T time control switch, covering installation, operation, settings, and maintenance.
The KG316T time control switch is designed for AC 220 V 50/60 Hz control circuits and can automatically turn loads on and off according to user‑set timing. It is suitable for lighting, signage, production equipment and other appliances that require scheduled power control.
The manual provides safety warnings, wiring diagrams for direct and expanded control, step‑by‑step timing configuration, fault troubleshooting, warranty information and ordering details. Installation should be performed by qualified personnel and the device must be mounted vertically in a stable location. This manual is written in Chinese.
| Rated control voltage | AC 220 V 50 Hz |
|---|---|
| Maximum load current | 20 A |
| Power consumption | ≤1.5 VA |
| Timing range | 1 min ~ 168 h |
| Timing error | ≤2 seconds/day |
| Mechanical life | ≥30 000 cycles |
| Electrical life | ≥10 000 cycles |
| Installation method | Device‑type, rail‑type |
The KG316T is rated for AC 220 V 50 Hz control voltage.
The switch can handle a load current up to 20 A.
The device supports 16 on‑times and 16 off‑times, for a total of 32 timing steps.
