A catalog of Pennine's silent bottle conveyor chains, including double‑pin, single‑pin, full‑ring and custom options.
Pennine Industrial Equipment Ltd. of Huddersfield, UK, manufactures silent inverted‑tooth chains for bottle handling. The catalog describes a full range of chain types—double‑pin, single‑pin, full‑ring, double‑ring, and spacer‑type—designed for high‑speed glass bottle production and various environmental conditions.
Technical details such as part numbers, pitch, width, maximum load, and compatible sprockets are provided, along with accessories like the Pennlock quick‑connect system and PennGuard protective inserts. Custom dimensions and materials (e.g., stainless‑steel 420) are also offered. This manual is written in Chinese.
| Pitch | 19 mm |
|---|---|
| Tooth range (sprocket) | 17 to 84 teeth |
| Standard width (center‑guide chain) | 100 mm to 400 mm |
Pennine provides the Pennlock industrial quick‑connect system, which reduces chain‑to‑machine connection time.
The full‑ring chain, made 100 % of chain rings, offers the greatest working surface and stability for small or easily tipped bottles.
They use grade 420 stainless steel, which can be hardened to provide wear resistance comparable to carbon‑steel chains.
Center‑guide chains are available in standard widths from 100 mm (4 in) up to 400 mm (16 in), with custom widths also possible.
