Performance specifications for the P&N Technology HP-127120-40X44 W150mm thermoelectric cooler, including cooling capacity, temperature difference, current…
This datasheet provides the key performance parameters of the P&N Technology HP-127120-40X44 W150mm thermoelectric cooler. It lists hot‑side temperature options, maximum cooling power, temperature differential, electrical limits and module resistance.
The document also includes a mechanical drawing of the module and operation tips such as the maximum operating temperature of 90 °C, the requirement not to exceed Imax or Vmax, and a note to contact P&N Technology for moisture and corrosion protection options. This manual is written in Chinese.
| Maximum Cooling Capacity (Qmax) | 106 W / 115 W |
|---|---|
| Maximum Temperature Difference (ΔTmax) | 68 °C / 75 °C |
| Maximum Input Current (Imax) | 12 A |
| Maximum Input Voltage (Vmax) | 14.5 V / 16.3 V |
| Module Resistance | 1.08 Ω / 1.22 Ω |
| Parameter Tolerances | ±10 % |
The maximum operating temperature is 90 °C.
The module must not be operated above 12 A of current, and the voltage limit is 14.5 V at 25 °C or 16.3 V at 50 °C.
Contact P&N Technology for moisture and corrosion protection options.
