This datasheet details the NovaStar K16 All-in-One video controller, featuring 4K processing, multiple input/output interfaces, and V-Can software control…
The NovaStar K16 is an All-in-One product designed to integrate video processing, video control, and LED screen configuration. It supports high-definition image processing up to 4K×2K@60Hz and can send processed video via Ethernet or fiber optic ports. The device is controlled by the intelligent V-Can software to achieve rich picture splicing effects. This manual is written in Chinese.
| Power Input | AC100-240V ~, 50/60Hz, 2.1A |
|---|---|
| Operating Temperature | 0℃～45℃ |
| Storage Temperature | -10℃～60℃ |
| Dimensions | 482.6mm ×373.0mm ×94.6mm |
| Net Weight | 6.2 kg |
| HDMI Input Resolution | 3840×2160 @60Hz |
| DP Input Resolution | 3840×2160@60Hz |
| Ethernet Output Ports | 16 ports |
The device is controlled by the intelligent management software V-Can.
Yes, it supports HDR output to enhance display quality and make colors more vivid.
