Official Nilfisk user manual for the TORNADO PR high‑pressure washer with safety, operation, maintenance and technical data.
This manual provides safety instructions, setup steps, and operating guidelines for the Nilfisk TORNADO PR high‑pressure washer. It covers symbols, safety precautions, mounting of components, wiring, water connection, and proper use of accessories such as the Click&Clean nozzles.
The document also includes maintenance procedures, troubleshooting tips, warranty information, and a full set of technical specifications. Contact information for Nilfisk distributors worldwide is listed at the end of the manual.
| Rated voltage | 230‑240 V |
|---|---|
| Rated frequency | 50 Hz |
| Rated power consumption | 2.1 kW (130 mm) / 2.4 kW (140 mm) |
| Current | 9.5 A (130 mm) / 10 A (140 mm) |
| Protection class | Class I / Class II |
| Rated pressure | 12.5 MPa / 125 bar (130 mm) – 13.5 MPa / 135 bar (140 mm) |
| Maximum pressure | 13.0 MPa / 130 bar (130 mm) – 14.0 MPa / 140 bar (140 mm) |
| Rated water flow | 7.5 l/min (130 mm) – 7.0 l/min (140 mm) |
| Maximum water flow | 9.2 l/min (both models) |
| Maximum water inlet pressure | 1 MPa / 10 bar |
| Maximum water inlet temperature | 60 °C |
Wear shoes with non‑slip soles, goggles, ear protection and protective clothing.
The washer can be connected to a water inlet pressure of up to 1 MPa (10 bar).
Always disconnect the electrical plug from the socket prior to maintenance, cleaning or repair.
