The NHG N HG268 is a smart gloss meter with a 3.5‑inch touchscreen, triple‑angle measurement and GQC6 software for data management.
The NHG N HG268 gloss meter offers full‑touch operation, a large 3.5‑inch color display and the ability to measure gloss at three angles (20°, 60°, 85°) simultaneously. It includes the GQC6 quality‑management software for data storage, analysis and report printing, and supports multiple measurement modes such as basic, statistical, continuous and quality‑control.
Technical specifications include a measurement range of 0‑2000 GU at 20°, a repeatability of ±0.1 GU, a weight of about 350 g, dimensions of 160 × 75 × 90 mm, a 3200 mAh lithium battery for up to 10 000 measurements, USB/RS‑232 interfaces, and operating temperature from 0 °C to 40 °C with humidity below 85 %RH. This manual is written in Chinese.
| Measurement angles | 20°, 60°, 85° |
|---|---|
| Measurement range (20°) | 0~2000 GU |
| Display | 3.5‑inch color touchscreen |
| Weight | ≈ 350 g |
| Dimensions (L×W×H) | 160 × 75 × 90 mm |
| Battery capacity | 3200 mAh lithium |
| Interface | USB, RS‑232 |
| Operating temperature | 0 °C – 40 °C |
| Maximum humidity | < 85 %RH |
It measures gloss at three angles: 20°, 60°, and 85°.
The large color screen can show up to five sets of test data simultaneously.
The GQC6 quality‑management software is included for data storage, analysis and quality‑control report printing.
